Operating System Windows 10 IoT Enterprise
Mobile Computing Platform
Intel® Atom Processor x7-Z8750 1.6GHz,
burst up to 2.56GHz
– 2MB Cache
VGA Controller
Intel® HD Graphics
Display
8.1″ Wide Viewing Angle TFT LCD WXGA (1280 x 800)
Protection film
600 nits LumiBond® display with Getac sunlight readable technology
Storage & Memory
4GB LPDDR3
Optional: 8GB LPDDR3
128GB eMMC
Optional: 256GB eMMC
Keyboard
Power button
5 tablet programmable buttons
Pointing Device
Touchscreen
– Capacitive multi-touch screen
– Optional: Dual mode touchscreen (multi-touch and digitizer)
Expansion Slots
Optional: 1D/2D imager barcode reader, Serial port, Ethernet i
Optional: SnapBack add-on: Smart card and HF RFID/NFC reader combo ii
Optional: SnapBack add-on: 2nd expanded battery ii
Optional: SnapBack add-on: Smart card and magnetic stripe reader ii
I/O Interface
FHD webcam x 1
8M pixels auto focus rear camera x 1
Audio in/out combo x 1
DC in Jack x 1
USB 3.2 Gen 1 Type-A x 1
Micro HDMI 1.4 x 1
Docking connector x 1
Optional: SIM card slot x 1 (Mini-SIM, 2FF) iii
Optional: RF antenna pass-through for GPS, WWAN and WLAN
Communication Interface
Intel® Wi-Fi 6 AX200, 802.11ax
Bluetooth (v5.2) iv
Optional: Dedicated GPS
Optional: 4G LTE mobile broadband iii
Optional: 10/100/1000 base-T Ethernet (Occupies expansion slot)
Security Features
TPM 2.0
Optional: SnapBack add-on: Smart card and HF RFID/NFC combo reader ii, v
Optional: SnapBack add-on: Smart card and magnetic stripe reader ii
Power
AC adapter (65W, 100-240VAC, 50/60Hz)
Li-ion battery (7.4V, typical 4200mAh; min. 4080mAh)
LifeSupportâ„¢ battery swappable technology (only with SnapBack 2nd expanded battery)
Dimension (W x D x H) & Weight
227 x 151 x 24 mm (8.93″ x 5.94″ x 0.94″) vi
0.88kg (1.94 lbs) vi
Rugged Features
MIL-STD-810H certified
IP65 certified
MIL-STD-461G certified
Vibration & 6ft (1.8m) drop resistant vii
Optional: ANSI/UL 121201, CSA C22.2 NO. 213 (Class I, Division 2, Groups A, B, C, D) viii
Environmental Specifications
Temperature ix:
– Operating: -21°C to 50°C / -6°F to 122°F
– Storage: -51°C to 71°C / -60°F to 160°F
Humidity:
– 95% RH , non-condensing
Pre-installed software
Getac Utility
Getac Camera
Getac Barcode Manager x
Getac Driving Safety Utility (trial version)
Getac KeyWedge Barcode Reader Utility (trial version)
Optional: Absolute Persistence®
Optional software
Getac Driving Safety Utility
Getac KeyWedge Barcode Reader Utility
Getac Device Monitoring System (GDMS)
Getac VGPS Utility xi
Accessories
Battery (7.4V, typical 4200mAh; min. 4080mAh)
AC adapter (65W, 100-240VAC)
Capacitive stylus with tether
Optional:
Carry bag
Battery (7.4V, typical 4200mAh; min. 4080mAh)
2nd expanded battery (14.4V, 2100mAh)
Multi-Bay charger (Dual-Bay)
Multi-Bay expanded battery dock with adapter (Six-Bay)
Multi-Bay charger (Eight-Bay)
AC adapter (65W, 100-240VAC)
Office dock AC adapter (90W, 100-240VAC)
MIL-STD-461 AC adapter (90W, 100-240VAC)
DC-DC vehicle adapter (120W, 11-32VDC)
Digitizer pen
Capacitive stylus with tether
Protection film
Hand strap
Shoulder strap (2-point)
Wrist strap
Vehicle cradle xii
Vehicle dock xii
Office dock
Bumper-to-Bumper warranty
Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime.
That is why Getac has introduced accidental damage as standard under our Bumper-to-Bumper warranty, to help minimize your enterprise IT costs.
Bumper-to-Bumper is your hassle-free guarantee. That means you can depend on us to have your unit back in service within days.
Standard
3 years Bumper-to-Bumper
